| 自锁式液压千斤顶 |
自锁千斤顶的设计是液压原理与机械原理的完美结合，在活塞杆整个冲程范围内都有螺纹，完全顶升后，可将止退挡圈旋下，直至顶住缸体，由止退挡圈及缸体受力，从而可以撤去油泵，实现千斤顶的自锁，特别适用于砼梁及砼桥的持续支撑及测试作业。螺母自锁使负载更安全，能经受住偏载荷达千斤顶额定承载能力的10％，溢流孔兼有限制行程的功能，它主要适用于发电厂、石油化工、机械制造安装以及曲线桥定位的机械锁定，该产品具有体积小、使用方便、操作灵活、工作省力、携带方便、节省安装时间、提高工作效率等特点。
自锁式液压千斤顶特性：
用于提升和机械负荷支撑。
螺纹活塞有耐磨镀层，缸体内壁镀硬铬。
绝对机械式锁定负载。
高温烤漆表面耐腐蚀及撞击。
千斤顶起升到指定高度，旋下锁定螺母即可撤去泵站，从而实现长 时间支撑负荷作业。
主要技术参数：
| 型号 |
承载能力T |
工作行程MM |
本体高度MM |
油缸外径MM |
活塞杆直径MM |
顶帽直径MM |
工作压力 |
| EK-CLL-50T-50 |
50T |
50 |
164 |
125 |
Tr95×4 |
70 |
70MPa |
| EK-CLL-50T-100 |
50T |
100 |
214 |
125 |
Tr95×4 |
70 |
| EK-CLL-50T-150 |
50T |
150 |
264 |
125 |
Tr95×4 |
70 |
| EK-CLL-50T-200 |
50T |
200 |
314 |
125 |
Tr95×4 |
70 |
| EK-CLL-50T-150-2 |
50T |
250 |
365 |
127 |
Tr95×4 |
70 |
| EK-CLL-50T-300 |
50T |
300 |
415 |
127 |
Tr95×4 |
70 |
| EK-CLL-100T-50 |
100T |
50 |
190 |
170 |
Tr130×6 |
80 |
| EK-CLL-100T-100 |
100T |
100 |
237 |
170 |
Tr130×6 |
80 |
| EK-CLL-100T-100-2 |
100T |
100 |
240 |
170 |
Tr130×6 |
80 |
| EK-CLL-100T-150 |
100T |
150 |
287 |
170 |
Tr130×6 |
71 |
| EK-CLL-100T-200 |
100T |
200 |
337 |
170 |
Tr130×6 |
80 |
| EK-CLL-100T-200-2 |
100T |
200 |
340 |
170 |
Tr130×6 |
80 |
| EK-CLL-100T-260 |
100T |
260 |
400 |
170 |
Tr130×6 |
80 |
| EK-CLL-100T-300 |
100T |
300 |
440 |
170 |
Tr130×6 |
80 |
| EK-CLL-150T-50 |
150T |
50 |
209 |
210 |
Tr160×6 |
110 |
| EK-CLL-150T-100 |
150T |
100 |
259 |
210 |
Tr160×6 |
110 |
| EK-CLL-150T-150 |
150T |
150 |
309 |
210 |
Tr160×6 |
110 |
| EK-CLL-150T-200 |
150T |
200 |
359 |
210 |
Tr160×6 |
110 |
| EK-CLL-150T-250 |
150T |
250 |
409 |
210 |
Tr160×6 |
110 |
| EK-CLL-150T-300 |
150T |
300 |
459 |
210 |
Tr160×6 |
110 |
| EK-CLL-200T-50 |
200T |
50 |
243 |
240 |
Tr190×6 |
120 |
| EK-CLL-200T-150 |
200T |
150 |
343 |
235 |
Tr185×6 |
130 |
| EK-CLL-200T-150-2 |
200T |
150 |
343 |
240 |
Tr190×6 |
120 |
| EK-CLL-200T-200 |
200T |
200 |
393 |
240 |
Tr190×6 |
120 |
| EK-CLL-200T-250 |
200T |
250 |
443 |
240 |
Tr190×6 |
120 |
| EK-CLL-200T-300 |
200T |
300 |
493 |
240 |
Tr190×6 |
120 |
| EK-CLL-250T-50 |
250T |
50 |
249 |
275 |
Tr215×6 |
135 |
| EK-CLL-250T-150 |
250T |
150 |
349 |
275 |
Tr215×6 |
135 |
| EK-CLL-250T-200 |
250T |
200 |
399 |
275 |
Tr215×6 |
135 |
| EK-CLL-250T-300 |
250T |
300 |
499 |
275 |
Tr215×6 |
135 |
| EK-CLL-300T-50 |
300T |
50 |
295 |
310 |
Tr240×6 |
150 |
| EK-CLL-300T-150 |
300T |
150 |
395 |
310 |
Tr240×6 |
150 |
| EK-CLL-300T-200 |
300T |
200 |
445 |
310 |
Tr240×6 |
150 |
| EK-CLL-300T-250 |
300T |
250 |
495 |
310 |
Tr240×6 |
150 |
| EK-CLL-300T-250-2 |
300T |
250 |
495 |
310 |
Tr240×6 |
150 |
| EK-CLL-400T-50 |
400T |
50 |
335 |
350 |
Tr265×6 |
170 |
| EK-CLL-400T-150 |
400T |
150 |
435 |
350 |
Tr265×6 |
170 |
| EK-CLL-400T-200 |
400T |
200 |
485 |
350 |
Tr265×6 |
170 |
| EK-CLL-400T-300 |
400T |
300 |
585 |
350 |
Tr265×6 |
170 |
| EK-CLL-500T-50 |
500T |
50 |
380 |
415 |
Tr305×6 |
190 |
| EK-CLL-500T-150 |
500T |
150 |
480 |
415 |
Tr305×6 |
190 |
| EK-CLL-500T-200 |
500T |
200 |
530 |
415 |
Tr305×6 |
190 |
| EK-CLL-500T-300 |
500T |
300 |
630 |
415 |
Tr305×6 |
190 |
| EK-CLL-600T-50 |
600T |
50 |
395 |
445 |
Tr330×6 |
215 |
| EK-CLL-600T-150 |
600T |
150 |
495 |
445 |
Tr330×6 |
215 |
| EK-CLL-600T-200 |
600T |
200 |
545 |
445 |
Tr330×6 |
215 |
| EK-CLL-600T-300 |
600T |
300 |
645 |
445 |
Tr330×6 |
215 |
| EK-CLL-800T-50 |
800T |
50 |
455 |
525 |
Tr380×6 |
255 |
| EK-CLL-800T-150 |
800T |
150 |
555 |
525 |
Tr380×6 |
255 |
| EK-CLL-800T-200 |
800T |
200 |
605 |
525 |
Tr380×6 |
255 |
| EK-CLL-800T-300 |
800T |
300 |
705 |
525 |
Tr380×6 |
255 |
| EK-CLL-1000T-50 |
1000T |
50 |
495 |
580 |
Tr430×6 |
295 |
| EK-CLL-1000T-150 |
1000T |
150 |
595 |
580 |
Tr430×6 |
295 |
| EK-CLL-1000T-200 |
1000T |
200 |
645 |
580 |
Tr430×6 |
295 |
| EK-CLL-1000T-300 |
1000T |
300 |
745 |
580 |
Tr430×6 |
295 |
| EK-CLL-1000T-500 |
1000T |
500 |
945 |
580 |
Tr430×6 |
295 |
|
|
 |
|
|
 |
|
